3-axis cnc machine (vmc) microcut challenger - vmc2418

Microcut Challenger VMC2418

Geographic location
Países Bajos / Babberich
View phone
ClassificationMilling centers
Name3-axis CNC machine (VMC) Microcut Challenger - VMC2418
Customer reference3-axis CNC machine (VMC) Microcut Challenger - VMC2418
BrandMicrocut Challenger
ModelVMC2418
Incorrect year2007
Details

Box Flat guide way contsruction
Very little used
ATC Drum 24 Positions
X - Travel:              610mm
Y - Travel:              455mm
Z - Travel:              520mm
Table Length:            762mm
Table Width:             363mm
Table load:              350
Feed rate X-Axis:        24000mm/min.
Feed rate Y-Axis:        24000mm/min.
Feed rate Z-Axis:        24000mm/min.
Spindle Taper:           40ISO/Bt/Mk
Power on spindle:        18kW
Speeds / ranges:         8000Rpm
ATC / revolver:          24
Number of controlled axis:3
Chip conveyor:           Yes
Coolantsystem:           Yes
Length:                  3500mm
Width:                   2300mm
Height:                  2600mm
Weight:                  3140kg


StatusSegunda mano
Information last updated30/10/2025 15:10:09
