Rectificadora cilíndrica universal danobat m50 #4612
DANOBAT M50
Geographic location
España / Badajoz, Spain
| Classification | Universal and exterior grinding machines |
|---|---|
| Name | Rectificadora Cilíndrica Universal DANOBAT M50 #4612 |
| Customer reference | 6555257 |
| Brand | DANOBAT |
| Model | M50 |
| Incorrect year | |
| Details | Distancia entre puntos: 500 mm
Altura de puntos: 100 mm
Ø de la muela: 300 mm
Anchura normal de la muela: 25 mm
Anchura maxima utilizable de la muela: 50 mm
Agujero de la muela: 127 mm
Cabezal porta-piezas: 75-110-150-220-275-375-550-750 rpm
Mesa inclinacion en grados: 8º
Velocidad hidraulica de la mesa: 0.10/6 m/min
Avance rapido automatico: 20 mm
Avance en profundidad: 0.10 a 1 mm
Velocidad avance en plongee: 0.10-5 mm/min
Regulacion del tiempo afino en segundos: 60 s
Motor cabezal porta-piezas: 2velocidades: 0.38/0.55 CV
Motor cabezal porta-muelas: 3 CV
Motor bomba hidraulica: 0.5 CV
Motor bomba refrigeracion: 0.10 CV
Aparato de rectificar interiores: 0.75 CV
Puntos: Morse 4 y 3
Peso aprox: 1600 Kg
Adjuntos
Más información de la fuente |
| Status | Segunda mano |
| Information last updated | 23/07/2025 14:48:04 |
