Laminadora de roscas seny d-40 h #4608
SENY D-40 H
Geographic location
España / Badajoz, Spain
| Classification | Roll forming machines |
|---|---|
| Name | Laminadora de roscas SENY D-40 H #4608 |
| Customer reference | 6555246 |
| Brand | SENY |
| Model | D-40 H |
| Incorrect year | |
| Details | Presion de laminado: 100 kN
Ø Piezas: 2mm min; 40mm max
Paso: 3.5mm max
Paso de acanalado: 1.75mm max
Anchura rodillo: 70mm
Ø rodillo: 80mm min; 120mm max
Velocidad ejes para rodillos: 32 51 95 150 rpm
Ø eje porta-rodillos: 40 estandar
Distancia entre ejes: 80mm min; 165mm max
Carrera de trabajo: 7 min
Avance: de 0.5mm/s hasta 6mm/s
Tiempo de laminado: de 0.1s hasta 100s
Tiempo de pausa: de 0.1s hasta 100s
Motor principal: 3 Kw
Potencia electrica consumida: 4.68 Kw
Capcidad deposito: 80 L
Peso aprox: 750 Kg
Adjuntos
Más información de la fuente |
| Status | Segunda mano |
| Information last updated | 23/07/2025 14:48:04 |
