Portal milling machineWALDRICH SIEGEN - PF-F-150

MACH-ID 9456Make:WALDRICH SIEGENType:PF-F-150

X - Travel:                  12000mm
Y - Travel:                  7300mm
Z - Travel:                  3000mm
Table Length:                12000mm
Table Width:                 4730mm
Table load:                  250000
Spindle Taper:               Milling Spindle 560 mm / Iso 60ISO/Bt/Mk
Power on spindle:            100kW
Speeds / ranges:             2500Rpm
Coolant through spindle / Bar:20
Number of controlled axis:   5
Length:                      30000mm
Width:                       12000mm
Height:                      10475mm
Weight:                      400000kg

Rebuild in 2004 for EUR 2.200.000 !This CNC Waldrich Portal milling machines was used in the Energie Field for steam turbien case machining.
